AC 3.045-1 City
Produkta apraksts
Fits Everywhere. With its short base boom of just 7.8m the AC 3.045 City is able to work in buildings with a relatively low clearance while still keeping its boom at a steep angle, enabling it to lift heavy loads indoors.This compact, 3-axle unit stays under 12t axle load limits even when outfitted with its full equipment for outstanding transportability. The addition of Flex Base with stepless outrigger positioning adds further versatility and improved performance for HA, MS, and telescopable loads. The new electrohydraulic E-Pack enables zero emissions and quieter operation – perfect for indoor work.
Preces specifikācija
Maksimālā kravas pacelšanas spēja
45 t
45 t
Galvenā masta garums
7.8 m – 31.2 m
7.8 m – 31.2 m
Mastu pagarinājums
1.1 m / 7.1 m – 13 m
1.1 m / 7.1 m – 13 m
Maksimālais pacelšanas augstums
46 m
46 m
Maksimālais pretsvārstekļu svars
5.3 t
5.3 t
Iztvērēju bāzes
6.40 m x 6.20 m
6.40 m x 6.20 m
Cēlājvadu vilkšana
4.4 t
4.4 t
Maksimālais rādiuss
36 m
36 m
Izmēri
L: 8.70 m W: 2.55 m H: 3.18 m
L: 8.70 m W: 2.55 m H: 3.18 m
Asis
3
3
Dzinējs
Mercedes
Mercedes
Piedziņa
6 x 4 x 6 (6 x 6 x 6)
Lejupielādēt specifikāciju6 x 4 x 6 (6 x 6 x 6)
